Tesoo CCTV Wide Angle Lens

Tesoo provides premium quality cctv wide angle lens with excellent reliability and performance, which can be used under extreme environment. Part of the wide angle lenses are warmly welcomed by vehicle applications, which can work stablely under -40℃~+105℃. Tesoo has various types of wide angle lenses, TTL: 10mm~24mm. EFL: 1.6mm~3.6mm. F.NO: F1.2~F2.8. Get CCTV camera wide angle lens price from Tesoo, the professional cctv lens suppliers now!

Buy Tesoo CCTV Wide Angle Lens   >

Sliding

02

Specifications of Tesoo CCTV Wide Angle Lens


Cctv Camera Wide Angle Lens
Cctv Wide Angle Lens
Cctv Camera Wide Angle Lens
Cctv Wide Angle Lens
PART No.TS-2722L-A01
TTL21.6mm
EFL3.6mm
F/NOF2.2
MBFL4.65mm
SENSOR  SIZE1/2.7"
FOV
(D)117°
(H)96°
(V)51°
MAX IMAGE CIRCLEφ7.2 mm
MountM12*0.5
CONSTRUCTION1G3P
DIAMENSIONSφ14*16.95
Operating temp.-10~ +70℃
Storage temp.15~ +75℃


Cctv Camera Wide Angle Lens
Cctv Wide Angle Lens
Cctv Camera Wide Angle Lens
Cctv Wide Angle Lens
Cctv Camera Wide Angle Lens
PART No.TS-2723N-A00
TTL22.5mm
EFL2.8mm
F/NOF2.0
MBFL4.34mm
SENSOR  SIZE1/2.7"
FOV
(D)138°
(H)114°
(V)60°
MAX IMAGE CIRCLEφ6.9 mm
MountM12*0.5
CONSTRUCTION4G
DIAMENSIONSφ14*18.16
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃


Cctv Wide Angle Lens
Cctv Camera Wide Angle Lens
Cctv Wide Angle Lens
Cctv Camera Wide Angle Lens
Cctv Wide Angle Lens
PART No.TS-2721O-A00
TTL20.85mm
EFL2.9mm
F/NOF2.2
MBFL5.3mm
SENSOR  SIZE1/2.7"
FOV
(D)148°
(H)122°
(V)64°
MAX IMAGE CIRCLEφ6.9 mm
MountM12*0.5
CONSTRUCTION2G3P
DIAMENSIONSφ14*16.1
Operating temp.-20 ~ +75℃
Storage temp.-25 ~ +80℃


Cctv Camera Wide Angle Lens
Cctv Wide Angle Lens
Cctv Camera Wide Angle Lens
Cctv Wide Angle Lens
Cctv Camera Wide Angle Lens
PART No.TS-2715Q-A00
TTL14.95mm
EFL2.52mm
F/NOF2.4
MBFL3.55mm
SENSOR  SIZE1/2.7"
FOV
(D)170°
(H)137°
(V)74°
MAX IMAGE CIRCLEφ7.0 mm
MountM12*0.5
CONSTRUCTION2G3P
DIAMENSIONSφ14*12.43
Operating temp.-20 ~ +75℃
Storage temp.-25 ~ +80℃
